5" BST 522 MK3

Diameter Speaker

5.25 inch

Lebar Daerah Frekuensi

129 - 9900 Hz

Sensitivity

91.5 dB

Medan Magnet

1.03 T

Berat Magnet

0.14 Kg

Diameter Voice Coil

20.4 mm

Impedansi

4 Ω

Nominal Power Handling¹

20 Watt

Program Power²

40 Watt

Material Voice Coil

KRAFT SV

Fs (Hz)

2 Ω: 117 Hz

4 Ω: Hz

DCR (Ω)

2 Ω: 3.6 Ω

4 Ω: Ω

Qts

2 Ω: 1.13

4 Ω: -

Qes

2 Ω: 1.44

4 Ω: -

Qms

2 Ω: 5.33

4 Ω: -

Mms (g)

2 Ω: 3.2 g

4 Ω: g

Cms (mm/N)

2 Ω: 0.58 mm/N

4 Ω: mm/N

BL Product (Tm)

2 Ω: 2.4 Tm

4 Ω: Tm

Vas (liters)

2 Ω: 4.6 liters

4 Ω: liters

No (%)

2 Ω: 0.49%

4 Ω: %

Sd (cm2)

2 Ω: 75.4 cm2

4 Ω: cm2

x_max (mm)

2 Ω: 1.33 mm

4 Ω: mm
