Diameter Speaker | 10 inch |
Lebar Daerah Frekuensi | 35 - 4100 Hz |
Sensitivity | 87 dB |
Medan Magnet | 0.7 T |
Berat Magnet | 0.82 Kg |
Diameter Voice Coil | 49.5 mm |
Impedansi | 4 Ω |
Nominal Power Handling¹ | 250 Watt |
Program Power² | 500 Watt |
Material Voice Coil | ASV |
Berat Speaker | 3 Kg |
Parameter “Thiele-Small” : | 2 Ω: 2 Ω2 Ω | 4 Ω: 4 Ω4 Ω |
Fs (Hz) | 2 Ω: 34 Hz34 Hz | 4 Ω: 34 Hz34 Hz |
DCR (Ω) | 2 Ω: 1.8 Ω1.8 Ω | 4 Ω: 3.6 Ω3.6 Ω |
Qts | 2 Ω: 0.570.57 | 4 Ω: 1.131.13 |
Qes | 2 Ω: 0.640.64 | 4 Ω: 1.411.41 |
Qms | 2 Ω: 5.365.36 | 4 Ω: 5.865.86 |
Mms (g) | 2 Ω: 83.8 g83.8 g | 4 Ω: 82.3 g82.3 g |
Cms (mm/N) | 2 Ω: 0.26 mm/N0.26 mm/N | 4 Ω: 0.27 mm/N0.27 mm/N |
BL Product (Tm) | 2 Ω: 7.1 Tm7.1 Tm | 4 Ω: 6.8 Tm6.8 Tm |
Vas (liters) | 2 Ω: 45.3 liters45.3 liters | 4 Ω: 46.6 liters46.6 liters |
No (%) | 2 Ω: 0.27%0.27% | 4 Ω: 0.13%0.13% |
Sd (cm2) | 2 Ω: 353 cm2353 cm2 | 4 Ω: 353 cm2353 cm2 |
x_max (mm) | 2 Ω: 8.24 mm8.24 mm | 4 Ω: 8.24 mm8.24 mm |
