Diameter Speaker | 12 inch |
Lebar Daerah Frekuensi | 35 - 3200 Hz |
Sensitivity | 90 dB |
Medan Magnet | 0.8 T |
Berat Magnet | 1.16 Kg |
Diameter Voice Coil | 49.5 mm |
Impedansi | 4 Ω |
Nominal Power Handling¹ | 300 Watt |
Program Power² | 600 Watt |
Material Voice Coil | ASV |
Berat Speaker | 4.2 Kg |
Parameter “Thiele-Small” : | 2 Ω: 2 Ω2 Ω | 4 Ω: 4 Ω4 Ω |
Fs (Hz) | 2 Ω: 34 Hz34 Hz | 4 Ω: 34 Hz34 Hz |
DCR (Ω) | 2 Ω: 1.8 Ω1.8 Ω | 4 Ω: 3.6 Ω3.6 Ω |
Qts | 2 Ω: 0.50.5 | 4 Ω: 0.890.89 |
Qes | 2 Ω: 0.540.54 | 4 Ω: 1.011.01 |
Qms | 2 Ω: 7.237.23 | 4 Ω: 7.27.2 |
Mms (g) | 2 Ω: 98.8 g98.8 g | 4 Ω: 97.8 g97.8 g |
Cms (mm/N) | 2 Ω: 0.22 mm/N0.22 mm/N | 4 Ω: 0.22 mm/N0.22 mm/N |
BL Product (Tm) | 2 Ω: 8.4 Tm8.4 Tm | 4 Ω: 8.7 Tm8.7 Tm |
Vas (liters) | 2 Ω: 75.2 liters75.2 liters | 4 Ω: 75.7 liters75.7 liters |
No (%) | 2 Ω: 0.55%0.55% | 4 Ω: 0.3%0.3% |
Sd (cm2) | 2 Ω: 498.8 cm2498.8 cm2 | 4 Ω: 498.8 cm2498.8 cm2 |
x_max (mm) | 2 Ω: 8.24 mm8.24 mm | 4 Ω: 8.24 mm8.24 mm |
