Diameter Speaker | 8 inch |
Lebar Daerah Frekuensi | 49 - 4600 Hz |
Sensitivity | 85 dB |
Medan Magnet | 0.57 T |
Berat Magnet | 0.48 Kg |
Diameter Voice Coil | 35.5 mm |
Impedansi | 4 Ω |
Nominal Power Handling¹ | 100 Watt |
Program Power² | 200 Watt |
Material Voice Coil | ASV |
Parameter “Thiele-Small” : | 2 Ω: 2 Ω2 Ω | 4 Ω: 4 Ω4 Ω |
Fs (Hz) | 2 Ω: 49 Hz49 Hz | 4 Ω: 49 Hz49 Hz |
DCR (Ω) | 2 Ω: 1.5 Ω1.5 Ω | 4 Ω: 3 Ω3 Ω |
Qts | 2 Ω: 0.910.91 | 4 Ω: 1.61.6 |
Qes | 2 Ω: 1.021.02 | 4 Ω: 1.951.95 |
Qms | 2 Ω: 8.668.66 | 4 Ω: 8.918.91 |
Mms (g) | 2 Ω: 40.5 g40.5 g | 4 Ω: 39.2 g39.2 g |
Cms (mm/N) | 2 Ω: 0.26 mm/N0.26 mm/N | 4 Ω: 0.26 mm/N0.26 mm/N |
BL Product (Tm) | 2 Ω: 4.3 Tm4.3 Tm | 4 Ω: 4.3 Tm4.3 Tm |
Vas (liters) | 2 Ω: 14.5 liters14.5 liters | 4 Ω: 14.7 liters14.7 liters |
No (%) | 2 Ω: 0.17%0.17% | 4 Ω: 0.09%0.09% |
Sd (cm2) | 2 Ω: 201.1 cm2201.1 cm2 | 4 Ω: 201.1 cm2201.1 cm2 |
x_max (mm) | 2 Ω: 7.1 mm7.1 mm | 4 Ω: 7.1 mm7.1 mm |
