Diameter Speaker | 10 inch |
Lebar Daerah Frekuensi | 38 - 3600 Hz |
Sensitivity | 86.5 dB |
Medan Magnet | 0.74 T |
Berat Magnet | 0.81 Kg |
Diameter Voice Coil | 49.5 mm |
Impedansi | 4 Ω |
Nominal Power Handling¹ | 150 Watt |
Program Power² | 300 Watt |
Material Voice Coil | ASV |
Parameter “Thiele-Small” : | 2 Ω: 2 Ω2 Ω | 4 Ω: 4 Ω4 Ω |
Fs (Hz) | 2 Ω: 38 Hz38 Hz | 4 Ω: 38 Hz38 Hz |
DCR (Ω) | 2 Ω: 1.8 Ω1.8 Ω | 4 Ω: 3.6 Ω3.6 Ω |
Qts | 2 Ω: 0.720.72 | 4 Ω: 1.311.31 |
Qes | 2 Ω: 0.810.81 | 4 Ω: 1.651.65 |
Qms | 2 Ω: 6.386.38 | 4 Ω: 6.316.31 |
Mms (g) | 2 Ω: 85.5 g85.5 g | 4 Ω: 85.8 g85.8 g |
Cms (mm/N) | 2 Ω: 0.21 mm/N0.21 mm/N | 4 Ω: 0.21 mm/N0.21 mm/N |
BL Product (Tm) | 2 Ω: 6.7 Tm6.7 Tm | 4 Ω: 6.7 Tm6.7 Tm |
Vas (liters) | 2 Ω: 36.3 liters36.3 liters | 4 Ω: 35.9 liters35.9 liters |
No (%) | 2 Ω: 0.23%0.23% | 4 Ω: 0.11%0.11% |
Sd (cm2) | 2 Ω: 353 cm2353 cm2 | 4 Ω: 353 cm2353 cm2 |
x_max (mm) | 2 Ω: 7.8 mm7.8 mm | 4 Ω: 7.8 mm7.8 mm |
